Supermicro 1029UZ-TN20R25M SuperServer SYS-1029UZ-TN20R25M

Optimised for Virtualisation, Cloud Computing and High Density Enterprise Server. 2x 25G SFP28 Ethernet ports, 20x Hot-swap 2.5" 7mm Drive Bays, Redundant Power Option.

  • Virtualisation
  • Cloud Computing
  • High Density Enterprise Server
  • Software Defined Storage
  • Dual Socket P (LGA 3647) support 2nd Gen. Intel Xeon Scalable processors (Cascade Lake/Skylake)‡
  • 24 DIMMs; up to 6TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM, Supports Intel Optane™ DCPMM
  • Up to 2 PCI-E 3.0 x8 slots (FH, FL); For 20 NVMe configuration, only 1 PCI-E 3.0 x8 is available For 18 NVMe configuration, 2 PCI-E 3.0 x8 will be available
  • 2x 25G SFP28 Ethernet ports
  • 20 Hot-swap 2.5" 7mm drive bays; up to 20 NVMe (CPU1: 8 NVMe + 2 NVMe/SAS/SATA3 hybrid, CPU2: 10 NVMe); 1 M.2 NVMe port, Optional extra M.2 NVMe and SATA3 ports
  • 8 Heavy duty fans w/ optimal fan speed control; 2 air shrouds
  • 1600W Redundant Power Supplies Titanium Level (96%)



Loading Configurator...

3 Years Warranty as Standard

Buy with confidence knowing all Broadberry CyberServe rack servers are backed up by our 3 year warranty, with further warranty upgrade options available.

Performance Breakthroughs

Powered by the revolutionary Intel Xeon SP processor range, delivering massive improvements in every metric over the previous generation of Xeon E7 and E5 processors.

Up to 12 DIMMs per CPU

This system is capable of supporting up to 12 DIMMS per CPU. That’s a significant advancement on the previous limit, which was 9 DIMMS per CPU.

Security Without Compromise

Intel Xeon Scalable Processor based servers feature security without compromise, incorporating a number of technologies that aid in safeguarding your system.

Accelerated Applications

Applications can be accelerated via the addition of Intel QAT (Quick Assist Technology) to a software-defined infrastructure environment.

Configure With Dual Processors

Featuring dual processors, this system enjoys boosts to its performance for multi-threaded programs, allowing for smooth performance for the most demanding CPU intensive applications.

Configure With Up to 6TB Of RAM

Equipable with up to an huge 6TB of RAM, which allows for quick and effective multi-tasking for even the most RAM intensive applications.

Optimised For Virtualisation

Designed to excel at virtualisation. You can use virtual machines for testing, to save physical space, to reduce costs, for hardware for increased compatibility and more.

Configure With Hot-Swap Drives

The Supermicro SYS-1029UZ-TN20R25M SuperServer | 1029UZ-TN20R25M features hot-swap hard drives, giving you more flexibility and allowing you to remove drives without having to shut down the system.

Configure with 2.5" Drives

The Supermicro SYS-1029UZ-TN20R25M SuperServer | 1029UZ-TN20R25M can be configured with 2.5" drives, a more space efficient and low noise option. These drives also offer energy savings and increased flexibility.

Featuring Dual 25GbE SFP28

Featuring a Dual 25GbE SFP28 network adapter, which delivers impressive performance. This server is free from vendor lock-in and features wide ranging hardware and software compatibility.


A 1U Supermicro SuperServer based on 2x Intel 2nd Gen Intel Xeon Scalable Processor (X11) range of processors, the Supermicro SYS-1029UZ-TN20R25M SuperServer | 1029UZ-TN20R25M is configurable with up to 0x Hot-Swap Drives drive bays, and designed for optimal performance with 24x 3200Mhz DDR4 memory sockets .

The Supermicro SYS-1029UZ-TN20R25M SuperServer | 1029UZ-TN20R25M supports the Intel Intel Xeon Scalable Processors 2nd Generation family in a high-density 1U form-factor. These SuperServers are ideal for network infrastructure, front-end enterprise, and minimal-downtime cluster server systems.

The Supermicro SYS-1029UZ-TN20R25M SuperServer | 1029UZ-TN20R25M boasts 2 PCI-Express slots for expandability, and as with all of our servers it can be fully customised online

Supermicro SYS-1029UZ-TN20R25M SuperServer | 1029UZ-TN20R25M Specs
  • Brand: Supermicro
  • U Size: 1U
  • Processor Family: 2nd Gen Intel Xeon Scalable Processor (X11)
  • Range: Virtualisation Supermicro SuperServers
  • High-Density Twin Servers:
  • Drive Bays: Hot-Swap Drives
  • HDD Size: 2.5" Drives
  • Maximum RAM Capacity: 3.1TB
